Maintaining Rz<1.5μm in Ultra-Low Profile (VLP) Copper Foil Processing
1. Definition & Importance of VLP Copper Foil
Ultra-Low Profile (VLP) copper foil requires surface roughness (Rz) <1.5μm for high-frequency (5G/mmWave) and Hdi Pcbs. Key benefits include:
-
Reduced signal loss: Lower surface resistance and scattering loss (0.2 dB/cm improvement @10 GHz);
-
Improved impedance control: Minimized dielectrIC thickness variation (±5% tolerance);
-
Enhanced adhesion: Smooth surfaces increase resin mechanical anchoring (20–30% peel strength gain).
2. Critical Process Controls
2.1 Foil Selection & Pretreatment
-
Foil types:
-
Electrodeposited: Nano-grained VLP foil (e.g., Mitsui ML-VLP, Rz=1.0–1.2μm);
-
Rolled: Multi-pass rolling (>90% reduction) + annealing (Rz=0.8–1.0μm).
-
-
Surface cleaning:
-
Alkaline degreasing (NaOH 5%, 50°C);
-
Acid pickling (H₂SO₄ 10%, 30s).
-
2.2 Chemical Etching Optimization
-
Etchant formulation:
-
H₂O₂ (8–12%) + H₂SO₄ (5–10%) with 0.1–0.3% BTA;
-
Temperature: 30±2°C.
-
-
Dynamic control:
-
Real-time etch rate monitoring (25–35 μm/min);
-
ORP sensor-controlled H₂O₂ dosing (ORP≥800 mV);
-
Spray pressure: 0.3–0.5 MPa.
-
2.3 Surface Microetching & Planarization
-
Microetching:
-
Na₂S₂O₈ (5%) + H₂SO₄ (3%), 30–60s (Rz improvement >30%);
-
Rate: 0.5–1.0 μm/min.
-
-
Mechanical polishing:
-
Diamond slurry (0.1–0.5μm), 0.1–0.3 MPa, 200–500 rpm;
-
Post-polish Rz: 0.5–0.8μm, Ra<0.1μm.
-
2.4 Electroplating & Coating
-
Copper plating:
-
Pulse plating (2 ASD forward, 20% reverse duty cycle);
-
Brighteners (PEG) + levelers (Janus Green B).
-
-
Anti-oxidation:
-
Electroless Ni (0.1–0.2μm, 7–9% P) or OSP coating.
-
3. Inspection & Process Control
-
Roughness measurement:
-
Laser confocal microscopy (Keyence VK-X3000, ±0.01μm);
-
AFM for Ra<0.1μm.
-
-
Real-time monitoring:
-
In-line white-light interferometry (5–10 points/roll);
-
SPC charts (UCL=1.5μm, LCL=0.8μm).
-
4. Case Study & Results
| Process Step | Parameters | Target Rz (μm) |
|---|---|---|
| Raw foil | VLP electrodeposited | 1.0–1.2 |
| Chemical etching | H₂O₂ 10%, 30°C, 2min | 0.8–1.0 |
| Mechanical polish | 0.3 MPa, 300rpm, 60s | 0.5–0.7 |
| Electroplating | Pulse current, 2 ASD | 0.7–0.9 |
Validation: A high-frequency PCB manufacturer achieved:
-
Rz reduced from 1.8μm to 0.9±0.2μm;
-
10 GHz insertion loss decreased by 0.25 dB/cm;
-
Lamination strength increased to 1.5 N/mm (IPC-TM-650 2.4.8).
