Knowledge Center

1. Radiation Mechanisms Radiation Sources: Common-Mode Currents: Unshielded edge traces act as monopole antennas (E∝ICM×L×f2) Edge Cavity Resonance: λ/4 waveguide modes (fres=c4Wεr​) Key Parameters:...

1. IP67 Core Requirements Test Condition Acceptance Criteria Dust Ingress 8h talcum powder spray Internal dust ≤0.1mg Water Immersion 1m depth × 30min No visible water ingress Pressure Cycling ±2kPa, 100 c...

1. Core Characteristics A Pushbutton Switch controls circuits via pressing operation, featuring: Tactile Feedback: Travel 0.5~5mm, force 0.5~5N Modular Design: Supports LED, seals, latching mechanisms Safety Rating: Up to IP69K (resists pre...

1. TMA Principles & Solder Properties Core Mechanism:TMA detects phase transitions via dimensional changes (0.1μm resolution): Expansion kink → Solidus temperature (Ts) Sharp contraction → Liquidus temperature (Tl) 2. Tes...

1. Thermal Damage Mechanisms & Thresholds Resin Sensitivity: PTFE/ceramic substrates degrade above 280°C (Dk shift >0.05) LCP crystallinity distortion >220°C under pressure (↑50% CTE anisotropy) Energy Accumulation: ...

1. Overview A Limit Switch is an electromechanical device that detects object position via mechanical contact or magnetic sensing to control circuit states. Core functions include: Safety Protection: Preents mechanical overtravel (e.g., crane anti-dr...

1. Drilling Damage Mechanisms Stress Concentration: Axial force >50N causes resin micro-cracks (depth >10μm) CTE mismatch (5.4 vs 60 ppm/°C) induces fiber-resin delamination Thermal Damage: Friction heat >300°C at >180...

1. Core Thermal Management Strategies Localized Temperature Control: Micro nozzles (ID≤0.5mm) or pulsed laser heating (spot accuracy ±0.05mm) Heat Affected Zone (HAZ) confined within 0.15mm of target component Temperature Gr...

1. Compensation Principle Functional Requirements: Offset hole wall absorption (consumes 15~35% paste) Ensure complete vertical fill (target fill rate ≥95%) Core Formula:Actual Paste Required = Vhole​×ρ×(1+Kcomp?...

1. Test Standards & Conditions Environmental Parameters: Temperature: 85°C ±2°C Humidity: 85% RH ±5% RH Duration: 168 hours (7 days) per IPC-TM-650 2.6.2 Sample Preparation: Cut into 50mm×50mm squ...
